RVC Carbon Foam Open Cell
RVC Carbon Foam Open Cell
Price range: $175.00 through $1,400.00
| Product | Open Cell Reticulated Vitreous Carbon (RVC) Foam |
| CAS No. | 7440-44-0 |
| Appearance | Black Porous Solid |
| Purity | 99.9% |
| Stock No | RVC-117-41 |
| Density Range | 3% to 5% |
| Thickness | 1 mm-50 mm (customization available) |
| PPI | 5, 10, 20, 30, 45, 60, 80, 95, 100, 110 (PPI customization available) |
| Size | 50 x 50 mm, 60 x 60 mm, 100 x 100 mm, 150 x 150 mm 250 x 250 mm, 275 x 330 mm, 300 x 300 mm ( Customization of sizes is also available.) |
Capacity
Choose an option
Add to cart
Buy Now
Physical and Chemical Properties
| Compression Strength | 15-75 psi (0.10-0.52 MPa) |
| Tensile Strength | 25-50 psi (0.17-0.34 MPa) |
| Shear Strength | 4.4×103 psi (30.3 Mpa) |
| Mohs Hardness | 6-7 Mohs |
| Specific Heat | 0.3 BTU/lb °F (1.26 J/g °C) |
| Shear Modulus | 4.4 × 103 psi (30.3 MPa) |
| Modulus of Elasticity (Tension) | 14.6 × 103 psi (101.84 MPa) |
| Shear Modulus | 4.4 × 103 psi |
| Bulk Thermal Conductivity | 0.021 – 0.029 BTU/ft ·hr·°F (0.033 – 0.050 W/m °C) |
| Coefficient of Thermal Expansion | At (0-100°C) 1.2 × 10-6 in/in°F (2.2 × 10-6 m/m°C) At (100-1000°C) 1.8 × 10-6 in/in°F (3.2 × 10-6 m/m°C) |
| Bulk Resistivity | 12.7 × 10-2 ohm · in (32.3 × 10-2 ohm · cm) |
| Temperature In air | 600°F (315°C) |
| Limitations Inert environment | 6330°F (3499°C) |
| Pore Sizes | 0.040″, customization is also possible |
Why is Aritech® Reticulated Vitreous Carbon (RVC) foam so special?
Aritech® manufacture and distribute worldwide the different shape and size of RVC foam of unique and repeatability properties by a patented technology on affordable prices for research and industrial applications in various sectors. Aritech® RVC is a rigid, highly porous and permeable structure and has a controlled density of carbon per unit volume. The matrix of cells and ligaments is completely repeatable, regular, and uniform throughout the entirety of the material.
Applications:
Porous Electrodes
High-Temperature Insulation
High-Temperature Oven Racking
Filters
Demisters
Storage Batteries
Scaffolds
Semiconductor Manufacturing
Acoustic Control
Vitreous or Glassy carbon is a form of pure carbon produced by the thermal decomposition of a three-dimensionally crosslinked polymer. It has high flexural strength. The zero open porosity gives a low permeability to gases. Glassy carbon has excellent resistance to a wide range of aggressive chemical environments and can, therefore, be used as an alternative material to precious metals for laboratory equipment and, for example, for electrodes in polarography.
Vitreous Carbon Foam has an open pore structure and extremely high porosity, giving a high surface area and low resistance to fluid flow. It is chemically inert in non-oxidising environments over a wide temperature range, maintains strength at high temperatures and is thermally insulating yet electrically conducting. Applications include use as porous electrodes, thermal insulation, filtration, substrate support, and acoustic control.
Unique Features:
- Low Density
- High-Temperature Stability
- High Strength to Weight Ratio
- High Surface area to Volume Ratio
- isotropic load response
- controlled stress-strain Characteristic
- the controlled density of carbon per unit volume
- completely repeatable, regular, and uniform
- Thermally Insulating
- Highly electrically conductive
- Low Thermal expansion
- High-Quality RVC Density
Application areas
Microscopy and Microanalysis, Metallurgical, Laboratory Research, Vacuum Evaporation, Semiconductor & Electronics, Nuclear, Aerospace
Other Unique Features
The key features are: High purity, resistance in inert gas or vacuum up to 3000°C and in air up to 600°C, corrosion resistance, Impermeability to gas and liquids, no open porosity, high hardness and strength, low density, extreme resistance to thermal shock, good electrical conductivity, no wetting by many saline, metallic and ceramic melts, physical and chemical properties are isotropic
